LS DYNA for solving crashes, metal forming, forging, large deformations, and failure
LS DYNA has built on over 20 years of development and is a general-purpose finite element program capable of simulating complex real world problems. It is used by the automobile, aerospace, construction, military, manufacturing, and bioengineering industries.
For Success - Partner with an expert. EnginSoft has extensive experience with LS DYNA. We have used it on many consulting projects and have some of the leading expert engineers.
LS DYNA capacities include multi-physics, CFD (compressible and incompressible), frequency domain dynamics, NVH, electromagnetism, conjugate heat transfer, mesh free methods, discrete element method, complete fluid-structure, SPH-structure capabilities. LS DYNA is optimized for shared and distributed memory Unix, Linux, and Windows based, platforms, and it is fully QA'd by LSTC. The code's origins lie in highly nonlinear, transient dynamic finite element analysis using explicit time integration.
"Nonlinear" means at least one (and sometimes all) of the following complications:
- Changing boundary conditions (such as contact between parts that changes over time)
- Large deformations (for example the crumpling of sheet metal parts)
- Nonlinear materials that do not exhibit ideally elastic behavior (for example thermoplastic polymers)
"Transient dynamic" means analyzing high speed, short duration events where inertial forces are important. Typical uses include:
- Automotive crash (deformation of chassis, airbag inflation, seatbelt tensioning)
- Explosions (underwater Naval mine, shaped charges)
- Manufacturing (sheet metal stamping)
Woodrail Road Barrier Impact Analysis
The Woodrail® road barrier is designed to improve vehicle safety blending in with the surrounding environment. The barrier has been thoroughly tested and certified against car and bus impact conditions.
- Environmental
- Crash
- LS DYNA
- Case Study
This study was part of the Virtual Optimization PAsta production process (OPAV) research project, which resulted in a simulation model that could be used by industrial pasta manufacturers to help them improve the quality and production process of their pasta..
- Food & Beverage
- FEA
- LS DYNA
- Case Study
Flexible Belts Case Study
Facilitates extraction of stresses and strains from entire structure and takes into account all friction forces, shape and misalignment dynamics and structural flexibility
- Automotive
- Multibody Dynamics
- RecurDyn
- Case Study
Estimation of tsunami damage to vehicles using LS DYNA
In this technical article, we demonstrate how to apply a one-way coupling technique using a combination of Particleworks and LS-DYNA to estimate tsunami damage to a vehicle.
- Environmental
- CFD
- LS DYNA
- Case Study
